egui for Flutter

A Flutter widget kit mirroring the compact immediate-mode style of Rust's egui. Dark-mode-first, compact, and built for inspector panels, debug overlays, editor tools, and game-engine style interfaces.

---

Features

• Compact, pixel-dense widgets that look at home in game-engine overlays, dev tools, and debug UIs
• Four Catppuccin themes out of the box: Mocha, Macchiato, Frappé, Latte (light)
• Custom palette support via EguiPalette
• ProggyVector bitmap font bundled — swap any font at runtime without rebuilding
• Draggable/collapsible windows, inspector columns, and docked panel layouts
• Inputs, tables, plots, sparklines, tree views, and an inline HSV color picker
• Custom controls styled independently from Material and Cupertino widgets

Widget catalogue

Widget	Description
EguiButton	Push button with toggled/active state
EguiSlider	Drag-to-change slider with label and value
EguiDragValue	Inline number field — drag to scrub, tap to type
EguiNumberInput	Integer spinner with explicit minus/plus buttons
EguiVec2 / EguiVec3	Paired drag-value fields for 2D/3D vectors
EguiProgressBar	Read-only fill bar with optional value label
EguiSparkline	Mini line chart for time-series data
EguiPlot / EguiSeries	XY line chart with grid, labels, and legend
EguiCheckbox	Compact checkbox
EguiToggle	Sliding on/off switch
EguiRadio / EguiRadioGroup	Single-select radio buttons
EguiCombo	Compact dropdown with prev/next arrows
EguiTextField	Single-line text input
EguiColorPicker	Expandable HSV color picker with optional alpha
EguiLabel	Plain and key/value row labels
EguiSeparator	Horizontal rule with optional label
EguiSection	Collapsible group with heading and divider
EguiTree / EguiTreeNode	Collapsible hierarchy/tree rows
EguiTable	Headered table with selectable rows
EguiScrollArea	Egui-styled scroll area with thin scrollbar
EguiTabBar	Compact tab strip with content panels
EguiPane	Collapsible titled panel for use inside EguiColumn
EguiColumn	Draggable inspector column — stacks panes, auto-scrolls
EguiWindow	Standalone floating window — draggable, collapsible
EguiPanel	Bare floating panel (no title bar)
EguiDockLayout	Top/bottom/left/right docked panel layout
EguiStatusText	Single-line status/info bar
EguiThemeChooser	Built-in palette picker

Getting started

Add to your pubspec.yaml:

dependencies:
  egui: ^0.1.2

Wrap your UI in EguiScope to provide the active theme to all descendant widgets:

import 'package:egui/egui.dart';

EguiScope(
  palette: EguiPalette.mocha,
  child: YourWidget(),
)

Usage

Basic inspector panel

EguiScope(
  palette: EguiPalette.mocha,
  child: EguiWindow(
    title: 'Inspector',
    collapsible: true,
    draggable: true,
    maxWidth: 260,
    child: Padding(
      padding: EdgeInsets.all(8),
      child: Column(
        crossAxisAlignment: CrossAxisAlignment.stretch,
        children: [
          EguiSlider(
            label: 'Opacity',
            value: opacity,
            min: 0, max: 1,
            valueLabel: opacity.toStringAsFixed(2),
            onChanged: (v) => setState(() => opacity = v),
          ),
          EguiCheckbox(
            label: 'Visible',
            value: visible,
            onChanged: (v) => setState(() => visible = v),
          ),
        ],
      ),
    ),
  ),
)

Inspector column (multiple collapsible panes)

EguiColumn(
  maxWidth: 260,
  children: [
    EguiPane(
      title: 'Transform',
      child: Column(
        crossAxisAlignment: CrossAxisAlignment.stretch,
        children: [
          EguiVec3(
            x: px, y: py, z: pz,
            speed: 0.05,
            onChanged: (x, y, z) => setState(() { px = x; py = y; pz = z; }),
          ),
        ],
      ),
    ),
    EguiPane(
      title: 'Material',
      child: EguiSlider(
        label: 'Roughness', value: roughness,
        min: 0, max: 1, valueLabel: roughness.toStringAsFixed(2),
        onChanged: (v) => setState(() => roughness = v),
      ),
    ),
  ],
)

When a pane collapses, the panes below slide up automatically.

Floating canvas window

EguiWindow can host any Flutter widget. For canvas-style content such as InfinityCanvas, make the window resizable and give it explicit bounds:

EguiWindow(
  title: 'Node Graph',
  draggable: true,
  resizable: true,
  initialWidth: 900,
  initialHeight: 560,
  minWidth: 420,
  minHeight: 280,
  maxWidth: 1200,
  maxHeight: 800,
  contentPadding: EdgeInsets.zero,
  child: InfinityCanvas(
    controller: controller,
    enableCulling: true,
    layers: [
      CanvasLayer.positionedItems(
        id: 'nodes',
        items: nodes,
      ),
    ],
  ),
)

Docked editor layout

EguiDockLayout(
  top: EguiTopPanel(child: toolbar),
  left: EguiLeftPanel(
    initialWidth: 220,
    collapsible: true,
    child: sceneTree,
  ),
  right: EguiRightPanel(child: inspector),
  bottom: EguiBottomPanel(
    resizable: true,
    initialHeight: 140,
    child: console,
  ),
  center: viewport,
)

Tables, plots, and color

EguiScrollArea(
  maxHeight: 160,
  child: EguiTable(
    columns: const ['Name', 'Type', 'State'],
    rows: rows,
    selectedRow: selected,
    onRowTap: (i) => setState(() => selected = i),
  ),
)

EguiPlot(
  height: 120,
  yMin: 0,
  series: [
    EguiSeries(name: 'FPS', points: fpsPoints),
    EguiSeries(name: 'Frame ms', points: frameMsPoints),
  ],
)

EguiColorPicker(
  label: 'Albedo',
  color: albedo,
  onChanged: (c) => setState(() => albedo = c),
)

Theming

Switch theme at runtime by changing the palette passed to EguiScope:

EguiScope(
  palette: _palette,           // EguiPalette.mocha / .macchiato / .frappe / .latte
  child: ...
)

Switch to any font family registered by your app without rebuilding:

final palette = EguiPalette.mocha.withFont('MyInspectorFont', fontSize: 13);

Build a custom palette:

const myPalette = EguiPalette(
  name: 'My Theme',
  panelBg:   Color(0xEF1a1a2e),
  widgetBg:  Color(0xFF16213e),
  widgetHov: Color(0xFF0f3460),
  widgetPrs: Color(0xFF533483),
  sliderFill: Color(0xFFe94560),
  sliderHov:  Color(0xFFff6b81),
  text:      Color(0xFFe0e0e0),
  subText:   Color(0xFF9e9e9e),
  border:    Color(0xFF2a2a4a),
  borderHov: Color(0xFF4a4a8a),
  separator: Color(0xFF1a1a3e),
  heading:   Color(0xFFe94560),
);

Disable window/panel drop shadows:

EguiPalette.mocha.withFont('Proggy', shadows: false)
// or in a const palette:
const EguiPalette(... shadows: false)

Fonts

ProggyVector is bundled and registered as family 'Proggy' — it's the default and requires no extra configuration. The example app uses the same default font. To use your own font, pass it via EguiPalette.withFont or set fontFamily/fontSize on a custom palette.

Example

A full showcase is in the example/ directory. From the repository root, run:

cd example && flutter run

There is also a docking-focused demo:

cd example && flutter run -t lib/dock_demo.dart

License

MIT — see LICENSE.

Credits

This package is inspired by Rust's egui, but is not affiliated with or endorsed by the egui project.

It includes Catppuccin color palettes and bundles Proggy fonts. See THIRD_PARTY_NOTICES.md for third-party credits and license notes.
