FLASH: Fast Linked AF_XDP Sockets for High Performance Network Services

FLASH is a high-speed userspace library that makes it easy to build efficient, unprivileged AF_XDP applications for modern cloud and edge deployments.

Seamlessly integrated with the FLASH kernel, it extends AF_XDP to enable true zero-copy packet sharing between network functions (NFs) and network devices, unlocking performance that surpasses traditional AF_XDP chaining solutions.

Key Features

• Zero-Copy Packet Sharing: Unlock unparalleled throughput and minimal latency with zero-copy data paths between NFs and network devices.
• Unprivileged Operation: Run AF_XDP applications securely without root access simplifying deployment while maintaining isolation.
• Packet Isolation: Ensure strong packet-level isolation between NFs, even when sharing memory powered by Rust and FLASH kernel safeguards.
• Backward Compatibility: Chain existing AF_XDP applications in copy-based mode with no code changes — easy migration, no disruption.
• Flexible Deployment Options: Deploy seamlessly on bare metal or in containers for consistent, isolated environments. Works on standard Linux kernels too (without zero-copy chaining support).
• Multi tenant Support: Designed for shared environments — the OS remains in control of resources, ensuring safety and fairness when multiple users or tenants share the same host. Unlike DPDK, FLASH plays nicely in multi-tenant and cloud-native setups.

Getting Started

Clone the repositories and install the FLASH kernel for zero-copy chaining support.

git clone https://github.com/networkedsystemsIITB/flash.git
git clone https://github.com/networkedsystemsIITB/flash-linux.git
cd flash
sudo ./usertools/flash_kernel/install.sh ../flash-linux

The install.sh script will build and install the kernel along with its modules.
It requires the path to the flash-linux repository as the first argument.
An optional second argument can be provided to specify the number of processors to use during the build.

During execution, the script will prompt you to choose between a quick build and a full build. Select the quick build option for faster compilation.

Follow the on-screen instructions provided in the terminal after installation to boot into the FLASH kernel.

For more details, refer to the FLASH Kernel Guide.

Building the userspace library and examples

FLASH has been tested on Ubuntu 24.04 and is expected to work similarly on Ubuntu 22.04.
Older versions (e.g., Ubuntu 20.04 or earlier) may encounter build issues due to missing dependencies.

Recommended Kernel Version: 5.17.5 or later for standalone NF operations.

Install the required dependencies using the following command:

sudo apt install -y build-essential meson libbpf-dev pkg-config git gcc-multilib clang llvm lld m4 libpcap-dev libcjson-dev libncurses-dev libnuma-dev

libxdp is not included in Ubuntu repositories — build it from source:

git clone https://github.com/xdp-project/xdp-tools.git
make PREFIX=/usr -j -C xdp-tools libxdp
sudo PREFIX=/usr make -j -C xdp-tools libxdp_install

Install Rust for using the Rust components of FLASH:

curl --proto '=https' --tlsv1.2 -sSf https://sh.rustup.rs | sh

Once dependencies are ready, build the library and examples:

make

Basic Usage

FLASH provides two primary userspace components:

1. NF Libraries: Used to build AF_XDP applications with FLASH support (available in C and Rust).
2. Monitor: A control-plane application that manages AF_XDP socket configurations and enables unprivileged NF operation.

Run a Sample L2FWD NF (Switch)

You can test a sample NF on any Linux kernel (no FLASH kernel required):

sudo ./build/monitor/monitor

A TUI will start, allowing you to configure AF_XDP.
Configurations are stored as JSON and can be loaded/unloaded on demand.

Load a sample configuration from config/simple_config.json, updating interface names as needed:

flash:/> load config config/simple_config.json

Then run the L2FWD example (no root needed):

./build/examples/l2fwd/l2fwd -u 0 -f 0 # C based NF
# or
./build/rust-target/release/l2fwd -u 0 -f 0 # Rust based NF

-u 0 → UMEM ID
-f 0 → NF ID
Both values are defined in the monitor configuration.

Chaining AF_XDP Applications with FLASH

FLASH allows chaining multiple AF_XDP-based network functions (NFs) together including independent NFs written in different languages using either copy-based or zero-copy modes.

• Copy-Based Chaining (Legacy Compatible):
  Works with any existing AF_XDP applications.
  Requires no code changes.
  FLASH-based NFs can also operate in this mode.
  Refer to the sysfs usage in FLASH Kernel Guide for copy-based setup instructions.

• Zero-Copy Chaining:
  Achieved when multiple NFs share the same UMEM region.
  Automatically handled by FLASH-based NFs.

Example: Linear Chaining Between Two AF_XDP Applications

Let’s consider chaining two independent L2 forwarders, one written in C and another in Rust. They only share the same UMEM region for zero-copy operation.

We can use config/chain-config.json as a starting point.

a. Start the monitor and load the configuration:

sudo ./build/monitor/monitor
flash:/> load config config/chain-config.json

b. Start the first l2fwd application (C based):

./build/examples/l2fwd/l2fwd -u 0 -f 0 -- -s 0 -c 1 -e 1

c. Start the second l2fwd application (Rust based):

./build/rust-target/release/l2fwd -u 0 -f 1 -s 1 -c 2 -e 2

d. Chain them using the monitor TUI:

flash:/> load route

The configuration file defines routes from flash_id 0 → flash_id 1. Upon loading, the monitor programs the FLASH kernel with these redirection rules.

You can then send packets to the first NF and observe them forwarded to the second at high throughput.

To extend chaining, add more NFs to the configuration file and specify their connections accordingly.

Docker Usage Instructions

Docker containers enable the consistent and isolated deployment of NFs in a portable development environment, facilitating the entry of NF developers into the setup process. To begin, you can create an image of the FLASH container.

# For NFs
make docker

# For Monitor
make docker_mon

It is noteworthy that in this setup, the monitor should be placed within a network namespace where the network interface (NIC) that the NFs will utilize is present. Additionally, the monitor requires root privileges to facilitate deployment. However, NFs can be isolated within unprivileged containers. The monitor can be initiated in the host otherwise within a privileged container using the following command:

docker run -rm -it --privileged -v /tmp/flash/:/tmp/flash/ --net=host flash:mon ./build/monitor/monitor

If the monitor is ready and running, the NF can be initiated using the following command:

docker run --rm -it -v /tmp/flash/:/tmp/flash/ flash:dev ./build/examples/l2fwd/l2fwd -u 0 -f 1

/tmp/flash contains a UDS socket that is used by NFs to communicate with the monitor.

You can also use docker compose to deploy multiple NFs at the same time.

docker compose up -d
