icecube

Microservice for processing images

📦 Installation   ⚙️ Configuration   📡 HTTP API   🚨 Bug report

Icecube is an image processing microservice written in Go. With this service, you can easily compress, convert, and resize images. It provides a RESTful API with support for multiple storage backends and asynchronous job processing. Packed in a lightweight Docker container for easy deployment.

Architecture

The project architecture can be divided into several modules.

Image Store is the module responsible for storing image blobs and metadata. It supports both disk storage and optionally external S3-compatible storage. Metadata is stored in PostgreSQL.

Job Store is the module responsible for storing image processing jobs. It uses the same PostgreSQL database.

Image Processor is the key module responsible for image processing (compression, resize, conversion). It uses external utilities such as ImageMagick, jpegoptim, libwebp, oxipng, and pngquant. All of them are lightweight and already included in the main Alpine image.

Worker Pool is the module responsible for asynchronous job processing. Optionally, it can notify about completed jobs to a Kafka topic. However, this is not required, since notifications about new jobs come from the Job Store module as soon as they appear.

A simple HTTP API interface is used for interacting with the service.

Installation

Docker (Recommended)

The fastest way to get started:

# Clone the repository
git clone https://github.com/cheatsnake/icecube.git
cd icecube

# Start with PostgreSQL and disk storage
docker compose --profile prod-postgres up

Available profiles:

Profile	Database	Storage	Description
dev	Memory	Memory	Quick local development
dev-postgres	PostgreSQL	Disk	Development with persistence
prod	PostgreSQL	Disk	Production deployment
prod-s3	PostgreSQL	S3	Production with S3 storage
prod-postgres	PostgreSQL	Disk	Production with managed DB
prod-postgres-s3	PostgreSQL	S3	Full production setup

Build from Source

Build prerequisites:

• Go 1.25 or later

Runtime dependencies:

For image processing, the following utilities must be installed in the system:

• ImageMagick
• jpegoptim
• libwebp
• oxipng
• pngquant

Build:

# Clone the repository
git clone https://github.com/cheatsnake/icecube.git
cd icecube

# Build the server
go build -o bin/server ./cmd/server

Run:

Development/test setup (in-memory):

./bin/server -config config/icecube.dev.json

Production setup (postgres + disk):

./bin/server -config config/icecube.json

Configuration

Icecube can be configured using environment variables or a JSON config file.

Environment Variables

All environment variables use the ICECUBE_ prefix:

Variable	Default	Description
ICECUBE_SERVER_PORT	3331	HTTP server port
ICECUBE_SERVER_MAX_WORKERS	4	Number of image processing workers
ICECUBE_LOG_LEVEL	info	Log level: debug, info, warn, error
ICECUBE_DATABASE_TYPE	memory	Database type: memory, postgres
ICECUBE_DATABASE_URI	-	PostgreSQL connection URI (required when DATABASE_TYPE=postgres)
ICECUBE_BLOB_TYPE	memory	Blob storage type: memory, disk, s3
ICECUBE_BLOB_DISK_PATH	/app/data/images	Path for disk storage
ICECUBE_BLOB_S3_BUCKET	-	S3 bucket name (required when BLOB_TYPE=s3)
ICECUBE_BLOB_S3_REGION	-	S3 region (required when BLOB_TYPE=s3)
ICECUBE_BLOB_S3_ENDPOINT	-	S3 endpoint (for S3-compatible storage)
ICECUBE_KAFKA_BROKERS	-	Kafka broker addresses (required when using Kafka)
ICECUBE_KAFKA_TOPIC	-	Kafka topic for job notifications

External Services Configuration

When using external services, configure their credentials via standard environment variables:

PostgreSQL:

Variable	Description
POSTGRES_DB	Database name
POSTGRES_USER	Database user
POSTGRES_PASSWORD	Database password

AWS S3:

Variable	Description
AWS_ACCESS_KEY_ID	AWS access key
AWS_SECRET_ACCESS_KEY	AWS secret key

Kafka: Uses ICECUBE_KAFKA_BROKERS and ICECUBE_KAFKA_TOPIC from the main table.

Config File

The config file is JSON with four main sections:

{
  "server": {
    "port": 3331,
    "maxWorkers": 4,
    "logLevel": "info"
  },
  "database": {
    "type": "",
    "uri": ""
  },
  "blob": {
    "type": "",
    "diskPath": "",
    "bucket": "",
    "region": "",
    "endpoint": ""
  },
  "kafka": {
    "brokers": "",
    "topic": ""
  }
}

Fields:

Section	Field	Type	Description
server	port	int	HTTP server port (default: 3331)
server	maxWorkers	int	Number of image processing workers (default: 4)
server	logLevel	string	Logging level: debug, info, warn, error (default: info)
database	type	string	Storage type: "memory" or "postgres"
database	uri	string	PostgreSQL connection URI (required when type=postgres)
blob	type	string	Blob storage: "memory", "disk", or "s3"
blob	diskPath	string	Path for disk storage (required when type=disk)
blob	bucket	string	S3 bucket name (required when type=s3)
blob	region	string	AWS region (required when type=s3)
blob	endpoint	string	Custom S3 endpoint for S3-compatible storage
kafka	brokers	string	Comma-separated Kafka broker addresses
kafka	topic	string	Kafka topic for job notifications

Note: Environment variables take precedence over config file values. If a value is set both in the config file and as an environment variable, the environment variable wins.

Example .env File

ICECUBE_DATABASE_TYPE=postgres
ICECUBE_DATABASE_URI=postgres://postgres:password@localhost:5432/icecube?sslmode=disable
POSTGRES_DB=icecube
POSTGRES_USER=postgres
POSTGRES_PASSWORD=password

ICECUBE_BLOB_TYPE=disk
ICECUBE_BLOB_DISK_PATH=/app/data/images

# S3 (optional)
# ICECUBE_BLOB_TYPE=s3
# ICECUBE_BLOB_S3_BUCKET=images
# ICECUBE_BLOB_S3_REGION=us-east-1
# AWS_ACCESS_KEY_ID=your-key
# AWS_SECRET_ACCESS_KEY=your-secret

# Kafka (optional)
# ICECUBE_KAFKA_BROKERS=localhost:9092
# ICECUBE_KAFKA_TOPIC=image-jobs

API Documentation

Base URL: http://localhost:3331

---

Health

GET /api/v1/health (Check if the service is running)

Response

http code	content-type	response
200	application/json	{"message": "Service is healthy"}

Example cURL

curl -X GET http://localhost:3331/api/v1/health

---

Images

POST /api/v1/images (Upload one or more images)

Request

multipart/form-data with a file field containing image file(s).

Responses

http code	content-type	response
201	application/json	[{id, originalName, format, width, height, byteSize}]

Example cURL

curl -X POST -F "file=@photo.jpg" http://localhost:3331/api/v1/images

GET /api/v1/image/{id}/metadata (Get metadata for a specific image)

Parameters

name	type	data type	description
id	required	string (UUID)	The unique image identifier

Responses

http code	content-type	response
200	application/json	{id, originalName, format, width, height, byteSize}
404	application/json	{"error": "Image not found"}

Example cURL

curl -X GET http://localhost:3331/api/v1/image/1a2b3c4d-5e6f-7a8b-9c0d-e1f2a3b4c5d6/metadata

GET /image/{id} (Download the image file)

Parameters

name	type	data type	description
id	required	string (UUID)	The unique image identifier

Responses

http code	content-type	response
200	image/*	Binary image data with Content-Type header set to the image format
404	application/json	{"error": "Image not found"}

Example cURL

curl -X GET http://localhost:3331/image/1a2b3c4d-5e6f-7a8b-9c0d-e1f2a3b4c5d6 -o image.jpg

---

Jobs

POST /api/v1/job (Create a job to process an image)

Request

name	type	data type	description
originalID	required	string (UUID)	The source image ID
options	required	array	Array of processing options

Image Processing Options

name	type	data type	description
format	optional	string	Output format: jpeg, png, webp
maxDimension	optional	int	Maximum width or height in pixels (0 = no resize)
quality	optional	int	Quality level 1-100 (100 = best quality, largest file)
keepMetadata	optional	bool	Preserve original image metadata (default: false)

Responses

http code	content-type	response
201	application/json	{id, status, originalID, tasks, createdAt}
400	application/json	{"error": "Invalid request"}
404	application/json	{"error": "Image not found"}

Job Statuses

Value	Description
pending	Job is waiting to be processed
processing	Job is currently being processed
completed	Job finished successfully
failed	Job failed (see reason field)

Example cURL

curl -X POST -H "Content-Type: application/json" \
  -d '{"originalID":"1a2b3c4d-5e6f-7a8b-9c0d-e1f2a3b4c5d6","options":[{"format":"webp","quality":80,"maxDimension":1000,"keepMetadata":false}]}' \
  http://localhost:3331/api/v1/job

GET /api/v1/job/{id} (Get the status of a processing job)

Parameters

name	type	data type	description
id	required	string (UUID)	The unique job identifier

Responses

http code	content-type	response
200	application/json	{id, status, reason, originalID, tasks, createdAt}
404	application/json	{"error": "Job not found"}

Example cURL

curl -X GET http://localhost:3331/api/v1/job/7b8c9d0e-1f2a-3b4c-5d6e-f7a8b9c0d1e2

---

CLI Tool

The CLI tool allows you to process images locally:

./bin/cli -input photo.jpg -format webp -max-dimension 1000 -quality 80

CLI Options:

Flag	Description
-input	Input image file path
-format	Output format (jpeg, png, webp)
-quality	Compression level (1-100)
-max-dimension	Maximum width or height in pixels
-keep-metadata	Preserve original metadata
-output	Output file path (default: input file with new extension)

Development

Running Locally with Docker Compose

# Development with in-memory storage
docker compose --profile dev up

# Development with PostgreSQL
docker compose --profile dev-postgres up

Makefile Commands

make build           # Build the server
make build-cli       # Build the CLI tool
make run             # Run the server
make test            # Run tests
make clean           # Remove build artifacts
make docker-build    # Build Docker image
make docker-up-dev   # Start Docker container (dev mode)
make docker-up-prod  # Start Docker container (prod mode)
make docker-down     # Stop Docker containers

License

MIT License
