Authentication

Authentication and Authorization

Authentication and Authorization in Arenal are compatable with OpenID Connect protocol.

Machine to machine (M2M)

In M2M case, client application request JWT without interaction with the user and uses it for further interaction with Arenal.

sequenceDiagram
    actor CONS as Client App
    participant KC as OpenID Provider
    participant ARN as Arenal

    CONS->>+KC: Request Token
    KC-->-CONS: Token (JWT)

    loop While JWT is valid
        CONS->>+ARN: Action Request
        ARN-->-CONS: Action Answer
    end

Loading

Example C# code looks like this:

using IdentityModel.Client;
using Skyware.Arenal.Client;
using Skyware.Arenal.Model;
using System.Text.Json;

namespace CliTestApp
{
    public class Program
    {

        private static TokenResponse? _tokenResponse = null;

        /// <summary>
        /// Demonstrates how to obtain and cache JWT
        /// </summary>
        /// <returns></returns>
        private static async Task<string> GetTokenAsync()
        {
            if (_tokenResponse == null)
            {
                using var client = new HttpClient();
                //Authenticate
                _tokenResponse = await client.RequestPasswordTokenAsync(new PasswordTokenRequest
                {
                    Address = "https://kc-dev.skyware-group.com/realms/arenal-dev/protocol/openid-connect/token",
                    ClientId = "api-client",
                    ClientSecret = "secret",
                    Scope = "api-scope",
                    UserName = "user",
                    Password = "password"
                });
            }
            return _tokenResponse.AccessToken;
        }

        private static async Task<Order> PublisOrderAsync(Order order)
        {
            using var client = new HttpClient();
            client.SetBearerToken(await GetTokenAsync());
            return await client.CreateOrdersAsync(order);
        }

        public static async Task Main(string[] args)
        {
            Order order = new Order()
            {
                Patient = new Person()
                {
                    GivenName = "Misho"
                    //Other properties
                }
                //Other properties
            };
            Order respOrd = await PublisOrderAsync(order);
            Console.WriteLine($"Order created, ArenalId is: {respOrd.ArenalId}");
            //Other interactions with Arenal
        }

    }
}
