Vivarium

Vivarium is a high-performance artificial life simulation written in C# (.NET 10) using the MonoGame framework.

The project simulates an ecosystem of autonomous agents ("Creatures") interacting within a dynamic grid-based world containing plants and structures.

📖 Documentation

Document	Description
Home	Introduction into the documentation
User Manual	Complete guide to understanding the simulation, neural networks, genetics, and ecosystem dynamics
Configuration Guide	Detailed configuration parameters and examples
API Documentation	Code reference generated from XML comments

🧬 Key Features

• Evolutionary Neural Networks: Agents possess a genome encoding a Recurrent Neural Network (RNN), allowing for memory and complex decision-making.
• Complex Phenotypes: Genes determine physical traits (Strength, Speed, Perception, etc.) and neural wiring.
• Dynamic Ecosystem:
  • Herbivores: Graze on plants, efficient metabolism, high resilience.
  • Carnivores: Hunt other agents, high energy cost, aggressive.
  • Omnivores: Adaptable diet, balanced traits.
• Emergent Behavior: Watch as agents evolve strategies for hunting, grazing, swarming, and combat without hard-coded rules.
• High Performance: Optimized using Span<T> and Struct-based architecture to support thousands of agents at 60 FPS.
• Interactive Camera: Full 2D camera support with zoom and panning to observe the simulation at macro and micro levels.
• Headless Mode: Run simulations without graphics for rapid training and data collection.

🎮 Controls

• WASD / Arrow Keys: Pan Camera
• Scroll Wheel: Zoom In/Out
• Left Click: Select Agent/Entity (View details in Inspector)
• Right Click: Deselect
• Space: Pause/Resume Simulation
• .(Dot): Step Forward One Tick (when paused)

🚀 Running the Simulation

Standard Mode (Visual)

Run the project normally through your IDE or terminal:

dotnet run --project src/Simulation/Vivarium.csproj -c Release

Note: Using Release configuration significantly improves performance.

Headless Mode (Fast Simulation)

For rapid evolution or data gathering, run in headless mode. This disables rendering and runs the simulation as fast as the CPU allows.

dotnet run --project src/Simulation/Vivarium.csproj -c Release -- --headless --duration 36000

• --headless: Enables headless mode.
• --duration <ticks>: Sets the simulation duration (60 ticks = 1 second). Default is 3600 (1 minute).
• --seed <int>: (Optional) Set a specific random seed for reproducibility.
• --config <path>: (Optional) Load simulation configuration from a JSON file.

⚙️ Configuration System

The simulation uses a modular configuration system that allows balancing parameters to be tweaked without code changes.

Configuration Files

Configuration can be loaded from JSON files using the --config argument:

dotnet run --project src/Simulation/Vivarium.csproj -c Release -- --config myconfig.json

Configuration Categories

Category	Mutability	Description
WorldConfig	Immutable	Grid size, entity pool sizes, seed
AgentConfig	Runtime	Agent balance (metabolism, reproduction, movement, combat)
PlantConfig	Runtime	Plant balance (photosynthesis, reproduction, aging)
BrainAIConfig	Runtime	Neural network and instinct parameters
GeneticsConfig	Partial	Mutation rate (mutable), genome structure (immutable)

Example Configuration

{
  "world": {
    "gridHeight": 96,
    "gridWidth": 170,
    "cellSize": 13,
    "agentPoolSize": 906,
    "plantPoolSize": 2040,
    "structurePoolSize": 510,
    "seed": 64
  },
  "agent": {
    "reproductionOverheadPct": 0.30,
    "baseMetabolismRate": 0.01,
    "maturityAge": 600,
    "reproductionCooldownFrames": 600
  },
  "plant": {
    "photosynthesisRate": 0.50,
    "shrivelRate": 0.40,
    "maturityAge": 600
  },
  "brain": {
    "hiddenNeuronDecayFactor": 0.5,
    "feedingInstinctThreshold": 0.6,
    "reproductionInstinctThreshold": 0.9
  },
  "genetics": {
    "genomeLength": 512,
    "traitGeneCount": 14,
    "mutationRate": 0.001
  },
  "framesPerSecond": 60.0
}

🛠️ Tech Stack

• Language: C# 14 / .NET 10
• Engine: MonoGame (DesktopGL)
• Architecture: Entity Component System (ECS) inspired, struct-based arrays for memory efficiency.
